RuoShui VC86E Digital Multimeter 22000 Auto Range pc connection port Temperature and bar graph multimetro Electrical tester

2 sold in last 8 hours
RuoShui
RuoShui 86E
50 In stock
Digital Multimeters
$62.14 $78.66
RuoShui 86E Digital multimeter 21999 Digit Precision multimeter frequency capacitance temperature with USB cable. 220mF Capacitor test Auto Range Resistor, Frequency, Temperature test With backlight and pc connection port Duty cycle test Model 86ESpecification Range Basic AccuracyDC Voltage 220mV/2.2V/22V/220V/1000V ±(0.05%+10)AC Voltage 220mV/2.2V/22V/220V/750V ±(1.0%+25)DC Current 220uA/2200uA/22mA/220mA/10A ±(0.5%+10)AC Current 220uA/2200uA/22mA/220mA/10A ±(1.2%+25)Resistance 220Ω/2.2kΩ/22kΩ/220kΩ/2.2MΩ/22MΩ/220MΩ...
$62.14
Terms & conditions
customers are viewing this product

RuoShui 86E Digital multimeter 21999 Digit Precision multimeter frequency capacitance temperature with USB cable.

  • 220mF Capacitor test
  • Auto Range
  • Resistor, Frequency, Temperature test
  • With backlight and pc connection port
  • Duty cycle test

Model 86E
Specification Range Basic Accuracy
DC Voltage 220mV/2.2V/22V/220V/1000V ±(0.05%+10)
AC Voltage 220mV/2.2V/22V/220V/750V ±(1.0%+25)
DC Current 220uA/2200uA/22mA/220mA/10A ±(0.5%+10)
AC Current 220uA/2200uA/22mA/220mA/10A ±(1.2%+25)
Resistance 220Ω/2.2kΩ/22kΩ/220kΩ/2.2MΩ/22MΩ/220MΩ ±(0.5%+30)
Capacitance 22nF/220nF/2.2uF/22uF/220uF/2.2mF22mF/220mF ±(2.5%+15)
Frequency 22Hz/220Hz/22kHz/220kHz/2.2MHz/22MHz/50MHz ±(0.1%+4)
Duty Cycle 5%-94.9%
Temperature (-20 ~1000)℃/(-4~1832)℉ ±(1.0%+5)
Features
Diode test √
Continuity buzzer √
Low battery indication √
Max./Min. Value √
Data hold √
Auto power off √
Bar graph display 46segment(20times/s)
USB interface jack √
Function protection √
Shockproof protection √
Frequency /duty cycle 5.0%~94.9%
Input impedance 10MΩ
Sampling rate 2 times/s
AC Frequency response (40~400Hz)
Operation way Manual/Auto range
LCD Size 70x50mm
Max. Display 21999
General Information
Power Supply 9V (6F22) (Not included)
Product Color Case: black; Holster color: orange
Product Weight Approx.410g
Product Size 192×95×48mm
Standard Accessories Test leads; Manual; TP02 temperature probe; USB cable; Software CD; batteryRuoShui or Victor VC86E Digital multimeter Package List

  • 1* VC86E Digtial Multimeter
  • 1 * Test leads
  • 1* Uesr's Manual
  • 1 * TP02 temperature probe
  • 1* USB cable
  • 1* Software CD
